30.000 V

 0.02%+ 2 counts (upper display)

30.000 V

 0.02%+ 2 counts (lower display)

100.00 mV

 0.02%+ 2 counts

-10.00 mV to 75.00 mV

 0.025 % + 1 count (via TC connector)

24.000 mA

 0.02%+ 2 counts

0.0 to 400.0 Ω

 0.1Ω (4-wire), 0.15Ω (2- and 3-wire)

401 to 1500 Ω

 0.5Ω (4-wire), 1Ω (2- and 3-wire)

1500 to 3200 Ω

 1Ω (4-wire), 1.5Ω (2- and 3-wire)

2.0 to 1000.0 CPM

 0.05 % + 1 count

1.0 to 1100.0 Hz

 0.05 % + 1 count

1.00 to 10.00 kHz

 0.05 % + 1 count

Sensitivity

 1 V peak-to-peak-minimum

Accuracy

 from 0.025% of range using any of 29 pressure modules.

 (for detailed specifications refer to pressure modules in options and accessories)

 Modules available for differential, gauge, vacuum, absolute, dual and high pressure.

100.00 mV

 0.02%+2 counts

10.000 V

 0.02%+2 counts

-10.00 mV to 75.00 mV

 0.025 % + 1 count (via TC connector)

24.000 mA (Source)

 0.02%+ 2 counts

24.000 mA (Simulate)

 0.02%+ 2 counts

15.0 to 400.0 Ω

 0.15 Ω (exc. current 0.15 to 0.5 mA), 0.1 Ω (exc. current 0.5 to 2 mA)

401 to 1500 Ω

 0.5 Ω(excitation current 0.05 to 0.8 mA)

1500 to 3200 Ω

 1 Ω(excitation current 0.05 to 0.4 mA)

2.0 to 1000.0 CPM

 0.05%

1.0 to 1100.0 Hz

 0.05%

1.00 to 10.00 kHz

 0.25%

Waveform:

 5 V p-p squarewave, -0.1 V offset

NI-120

 0.2 °C

PT-100 (385)

 0.33 °C

PT-100 (393)

 0.3 °C

PT-100 (JIS)

 0.3 °C

PT-200 (385)

 0.2 °C

PT-500 (385)

 0.3 °C

PT-1000 (385)

 0.2 °C

Resolution:

 0.1 °C

J:

 0.7 °C

K:

 0.8 °C

T:

 0.8 °C

E:

 0.7 °C

R:

 1.8 °C

S:

 1.5 °C

B:

 1.4 °C

L:

 0.7 °C

U:

 0.75 °C

N:

 0.9 °C

Resolution

 J, K, T, E, L, N, U: 0.1 °C, 0.1 °F B, R, S: 1 °C, 1 °F

XK

 0.6°C

BP

 1.2°C

NI-120

 0.2 °C

PT-100 (385)

 0.33 °C

PT-100 (393)

 0.3 °C

PT-100 (JIS)

 0.3 °C

PT-200 (385)

 0.2 °C

PT-500 (385)

 0.3 °C

PT-1000 (385)

 0.2 °C

Resolution:

 0.1 °C

Note:

 Accuracy stated for 4-wire measurement.

J:

 0.7 °C

K:

 0.8 °C

T:

 0.8 °C

E:

 0.7 °C

R:

 1.4 °C

S:

 1.5 °C

B:

 1.4 °C

L:

 0.7 °C

U:

 0.75 °C

N:

 0.9 °C

Resolution

 J, K, T, E, L, N, U: 0.1 °C, B, R, S: 1 °C

XK

 0.6°C

BP

 1.2°C

Source functions:

 Voltage, current, resistance, frequency, temperature

Ramps

 Slow ramp, Fast ramp, 25% step-ramp

Voltage:

 24 V

Accuracy:

 10%

Maximum current:

 22 mA, short circuit protected

Source functions:

 Voltage, current, resistance, frequency, temperature

Steps

 25% of range, 100% of range

 -10 °C to +55 °C

 -20 °C to 71 °C

 3000 m

 EN 61010-1:1993, ANSI/ISA S82.01-1994; CAN/CSA C22.2 No 1010.1:1992

 130 x 236 x 61 mm

 0.65 kg

 4 AA alkaline batteries

 Separate battery compartment, accessable without breaking calibration seal

 Pressure module connector, also used for remote real-time programming
