• Measure inductance/capacitance/resistance with secondary parameters including dissipation factor (D), quality factor (Q), phase angle (Ø), equivalent series/parallel resistance (ESR or Rp)

• Autoranging operation for AC impedance and DE resistance measurement

• Auto LCR smart check and measurement

• Series/Parallel modes

• Ls/Lp/Cp with D/Q/Ø/ESR parameters

• Support DCR mode 200 to 200MΩ

• High accuracy with 4 or 5 terminal Kelvin measurement

• Testing frequency is up to 10kHz and output frequency is up to 100kHz

• Dual display with backlight

• Data hold function

• Low battery indication with auto power off

• Dust and water proof to IP67

• Includes test leads and batteries

Inductance (F=1kHz)

• Range: 2000.0μH/20.000/200.0/2000.0mH/20.000/ 200.00/2000.0H

• Resolution: 0.1/1μH/0.01/0.1/1mH/0.01/1H

• Accuracy: ±(1.5% +15 dgt.)

Capacitance (F=1kHz)

• Range: 2000.0pF/20.000/200.00/2000.0nF/20.00/ 200.00/2000μF

• Resolution: 0.01/0.1/1pF/0.01/0.1/1nF/0.1μF

• Accuracy: ±(1.0% +10 dgt.)

Resistance (F=1kHz)

• Range: 20.000/200.00Ω/2.0000/20.000/200.00kΩ/ 2.0000/20.000/200.0MΩ

• Resolution: 0.01/0.1/1Ω/0.01/0.1/1kΩ/0.1MΩ

• Accuracy: ±(1.5% +5 dgt.)

• Test Frequencies: 100/120/1k/10k/100k Hz

• Test Signal Level: 0.5 VAC rms typical

• Power Supply: 6 x 1.5V AA batteries

• Dimensions: 220 x 96 x 60mm (8.6 x 3.7 x 2.4")

• Weight: 360g (0.8 lb)
