• Wide range measurements from 500V to 5000V and up to 60GΩ

• Sources up to 1.2mA current during tests to offset capacitance load

• Polarization index measurement (PI)

• Dielectric absorption ratio measurements (DAR)

• Time set measurement function

• Auto-discharge function and voltage output warning function

• Live circuit warning symbols plus audible warning

• Live circuit detection prevents insulation test if >30V is detected

• Max/Min, Peak, Relative value and Data Hold functions

• 6000-count digital display with bargraph and backlight

• Meets IEC61010-1 Cat. IV 600V safety standards

• Includes test leads, batteries and carrying case

Insulation Resistance

• Test Voltages: 500V, 1000V, 2500V, 5000V DC

• Measurement Range: 0 to 60.0GΩ

• Accuracy: ±5% rdg. +3 dgt.

• Open Circut Voltage: +20%, -0%

• Rated Current: 1 to 1.2mA

• Short Circuit Current: Approx. 1.3 mA

RESISTANCE TESTS

• Measurement Range: 0.1 to 6000Ω

• Accuracy: ±1.5% rdg. +10 dgt.

• Continuity Test: Buzzer sounds at <50Ω

• Short Circuit Current: ≥200mA

• Open Circuit Test Voltage: ≥4.5V

VOLTAGE TESTS

• Measurement Range: 0.5 to 600.0V AC/DC

• Accuracy: ±1.5% rdg. +5 dgt.

• Power Supply: 8 x 1.5V "C" R14 batteries

• Dimensions: 198 x 148 x 86mm (7.8 x 5.8 x 3.4")

• Weight: 1.5 kg (3 lb)
