Specifications

Digi XBee 3 802.15.4

PERFORMANCE

DATA RATE

RF 250 Kbps, Serial up to 1 Mbps

INDOOR/URBAN RANGE*

Up to 60 m (200 ft)

OUTDOOR/RF LINE-OF-SIGHT RANGE*

Up to 1200 m (4000 ft)

TRANSMIT POWER

+8 dBm

RECEIVER SENSITIVITY (1% PER)

-103 dBm Normal Mode

FEATURES

CONFIGURATION METHOD

API or AT commands, local or over-the-air (OTA)

FREQUENCY BAND

ISM 2.4 GHz

INTERFERENCE IMMUNITY

DSSS (Direct Sequence Spread Spectrum)

ADC INPUTS

(4) 10-bit ADC inputs

OPERATING TEMPERATURE

-40º C to 85º C (-40º F to 185º C)

PROGRAMMABILITY

MEMORY

1 MB / 128 KB RAM

CPU/CLOCK SPEED

HCS08 / up to 50.33 MHz

NETWORKING AND SECURITY

PROTOCOL

802.15.4

ENCRYPTION

128/256 bit AES

RELIABLE PACKET DELIVERY

Retries/Acknowledgements

IDS

PAN ID and addresses, cluster IDs and endpoints (optional)

CHANNELS

16 channels

POWER REQUIREMENTS

SUPPLY VOLTAGE

2.1 to 3.6 V

TRANSMIT CURRENT

135 mA @ 19 dBm

RECEIVE CURRENT

15 mA

POWER-DOWN CURRENT

2 micro Amp @ 25º C (77º F)

WARRANTY

WARRANTY

 1-year
